Canvases And Outputs

Canvases and outputs define the display topology that connects players, screens, and failover behavior. This area is usually maintained by admins, but operators should understand it well enough to interpret system state during incidents.

What A Canvas Or Target Represents​

In the current UI, much of this topology is managed through target-style configuration.

That configuration commonly includes:

  • a name
  • width and height
  • node count
  • failover mode
  • active output selection
  • output definitions
  • commands for output control and active-output detection

Even if operators do not edit this often, this configuration explains how a display surface is expected to behave in production.

General Configuration​

Typical top-level fields include:

  • Name
  • Width
  • Height
  • Nodes

These define the general display context and should match the physical or logical surface the target represents.

Failover​

Failover determines how SVRunner responds when multiple output paths exist.

The current configuration supports at least:

  • AUTO
  • MANUAL

In automatic failover mode, the system is expected to evaluate output state and switch according to configured logic.

In manual mode, operators or admins may need to intervene directly.

Active Output​

The configured Output represents the expected active output role.

This is important because dashboard and player-related views may compare player role to output state to determine what is currently on-screen.

Output Definitions​

Each target can define multiple outputs.

An output definition commonly includes:

  • name
  • role
  • command
  • output check

These definitions support:

  • multiple playback paths
  • active output determination
  • controlled switching
  • operational failover behavior

Canvas Or Target Sidebar Stub screenshot: target or canvas sidebar with failover mode, active output, and at least two configured outputs visible. Save final image at packages/docs/screenshots/app-canvas-target-sidebar.png.

Output Commands And Checks​

The UI exposes code-style fields for:

  • checking the active output
  • defining output commands
  • defining output-specific checks

These are advanced, deployment-specific behaviors and should be changed carefully.

If your installation depends on them, document local conventions clearly and validate every change against real hardware behavior.

How This Relates To Players And Screens​

  • players are assigned into this topology through targets and roles
  • screens rely on the topology for actual display routing
  • preview helps validate scheduled content, but it does not replace validation of the real output path

When troubleshooting, operators often need to interpret all three together:

  • the screen
  • the player state
  • the output or failover state

Target Panel Output State Stub screenshot: target panel or related operational view showing which player is currently on-screen versus available as backup. Save final image at packages/docs/screenshots/app-target-panel-output-state.png.

Typical Admin Workflow​

  1. Create or open the target or canvas configuration.
  2. Set the name and dimensions.
  3. Configure node count if used by the deployment.
  4. Set the failover mode.
  5. Define outputs and roles.
  6. Add or refine output commands and checks.
  7. Save and validate against the live display path.

Operational Guidance​

Use Care With Failover Changes​

Failover settings affect how the system behaves during degraded conditions.

Only change them when you understand:

  • which outputs are expected to be primary or secondary
  • how output checks determine active state
  • how operators will verify the result after a change

Validate Against Real Hardware​

A correct-looking configuration in the UI is not enough.

After changing outputs or failover logic, verify:

  • which output is actually on-screen
  • whether player roles match the intended output path
  • whether automatic switching behaves as expected
