System Components

SVRunner is a multi-part system rather than a single UI. This page describes the major runtime pieces in the current repo and how they fit together in a deployment.

Core Components​

The current workspace is organized around several major packages:

  • @svrunner/server
  • @svrunner/client
  • @svrunner/web-player
  • @svrunner/player-relay
  • @svrunner/docs
  • @svrunner/touch-player

Not every deployment uses every package directly, but these are the main system components represented in the repo.

Server​

The server is the core runtime component.

It is responsible for:

  • serving the GraphQL API
  • handling authentication
  • serving uploaded static assets
  • serving the built web application
  • serving the preview player
  • serving the documentation site
  • managing persistent runtime data such as the database, assets, and logs

In most deployments, the server is the central point operators and integrators talk to.

Web Application​

The client package is the main operator and admin interface.

It is responsible for:

  • content management
  • scheduling workflows
  • preview access
  • player, screen, and target administration
  • logs, licensing, users, systems, and extension configuration

The web app consumes the same GraphQL API exposed by the server.

Web Player / Preview​

The web-player package provides the preview-facing playback experience served at /preview.

It helps operators inspect generated playback results without relying only on the live display path.

Player Relay​

The player-relay package is a runtime integration component that communicates with the server and helps move or synchronize playback-related state and assets to downstream playback environments.

In operational terms, it sits closer to the playback edge than the main admin web application.

Touch Player​

The touch-player package is a specialized playback-side component based on TouchDesigner.

It is part of the broader playback ecosystem for installations that use that runtime.

Documentation Site​

The docs package is the Docusaurus documentation site served by the server at /docs.

This allows operational documentation to travel with the deployed application.

How The Pieces Communicate​

At a high level:

  • browsers use the client UI served by the server
  • the client talks to the server through GraphQL over HTTP and sometimes WebSocket
  • preview uses the preview route served by the server
  • player-side components communicate with the server and consume playback-related state and assets
  • the server serves static media through /static

System Components Diagram Stub screenshot: component diagram showing browser/client -> server -> static/docs/preview/graphql, plus player-side components connected to the server. Save final image at packages/docs/screenshots/architecture-system-components-diagram.png.

Operational Mental Model​

The simplest way to think about the system is:

  • the server is the control plane
  • the web app is the operator/admin interface
  • the preview/web-player is the generated-playback inspection interface
  • the player-side components are the runtime playback edge
