Linux Kiosk

This page documents the Linux kiosk setup used for dedicated player devices. The goal is a machine that boots directly into the playback application, supports remote access, and can be configured with stable network and player settings.

Intended Result​

The expected kiosk result is:

  • the machine boots directly into the Electron player app
  • SSH access is available
  • VNC access is available
  • the device behaves like a dedicated player rather than a general desktop workstation

Required Packages​

The existing kiosk notes install these packages:

sudo apt update && sudo apt install -y xinit xorg unclutter x11vnc curl openssh-server openbox python3

These provide:

  • X startup
  • the windowing environment
  • cursor hiding
  • remote VNC access
  • SSH access
  • the runtime shell and Python support used by the configuration script

Kiosk Session Startup​

The kiosk flow is driven by ~/.xinitrc.

The documented kiosk startup behavior includes:

  • logging to ~/kiosk.log
  • disabling screen blanking and DPMS
  • hiding the cursor with unclutter
  • launching x11vnc
  • launching openbox
  • waiting for network connectivity
  • starting the Electron player in kiosk mode

The current template uses a CONNECTIVITY_HOST value and waits until that host responds before launching the player app.

Manual Setup Steps​

  1. Install the required packages.
  2. Create ~/.xinitrc with the kiosk startup commands.
  3. Make ~/.xinitrc executable.
  4. Enable and start SSH.
  5. Test the kiosk session manually with startx.

Autologin And Automatic Startup​

The documented flow configures:

  • autologin on tty1
  • startx launch from ~/.bash_profile
  • optional fallback in ~/.profile
  • disabling the desktop login manager such as gdm

This ensures the box boots directly into the kiosk session instead of the normal desktop environment.

Configuration Script​

The provided configure-kiosk.sh script makes the setup more repeatable.

It currently handles:

  • VNC password creation
  • updating CONNECTIVITY_HOST in ~/.xinitrc
  • writing player settings into ~/.config/svr-electron-player/settings.json
  • setting:
    • serverAddress
    • serverPort
    • playerId
  • configuring a static IP address
  • using NetworkManager if available
  • falling back to netplan for supported wired interfaces

Inputs The Script Requires​

The documented script prompts for:

  • VNC password
  • CCS or server IP address
  • server port
  • player ID
  • player static IP address
  • netmask
  • gateway IP address
  • DNS servers

Have those values prepared before running the script.

Validation Checklist​

After setup, verify:

  1. the machine boots into the kiosk app automatically
  2. SSH access works
  3. VNC access works
  4. the player can reach the SVRunner server
  5. DISPLAY=:0 xrandr shows the expected display output
  6. ~/kiosk.log does not show startup failures

Linux Kiosk Device Stub screenshot: player device booted directly into the kiosk application. Save final image at packages/docs/screenshots/installation-linux-kiosk-device.png.

Linux Kiosk Remote Access Stub screenshot: successful remote access via VNC or SSH to the kiosk device. Save final image at packages/docs/screenshots/installation-linux-kiosk-remote-access.png.

Operational Notes​

Network Dependency​

The kiosk startup waits for connectivity before launching the player. If the configured connectivity host is wrong or unreachable, the player app may never launch.

Remote Access​

SSH and VNC are both part of the intended support model. Secure them appropriately for the deployment environment.

Static IP Changes​

The script can update static IP settings. Treat this carefully on remote devices to avoid locking yourself out during reconfiguration.
