Docker

This page documents the container deployment path for SVRunner. Use it when the server should run as a Docker container rather than a direct host installation.

What The Container Includes​

The current Docker packaging flow is designed to include the built:

  • server
  • client
  • docs site
  • preview player

At runtime, the container starts the server process, which then serves:

  • the web app at /
  • GraphQL at /graphql
  • static assets at /static
  • preview at /preview
  • docs at /docs

Base Runtime Expectations​

The existing Docker notes show a container that:

  • exposes port 8080
  • sets SVR_SERVER_PORT=8080
  • runs node index.js

This differs from the host-default port 7376, so be explicit in your deployment documentation and port mappings.

Build Flow​

The existing Docker packaging notes describe this flow:

  1. build the packaged application artifacts
  2. build the Docker image from the repository Dockerfile

The documented local command is:

pnpm run dockerbuild

This flow includes the app packaging step before the actual Docker image build.

Architecture Note​

The current Docker notes also call out a platform caveat:

  • if building on linux/arm64/v8, use --platform linux/amd64 with the current Docker setup

Example from the existing notes:

turbo run dockerpackage && docker build --platform linux/amd64 . -t <IMAGE_NAME>

Running The Container​

The documented local run flow is:

pnpm run dockerrun

At a practical level, your container deployment should include:

  • a published HTTP port
  • a mounted persistent data directory
  • the required environment variables

Persistence Requirements​

Do not run SVRunner with fully ephemeral storage.

The following data must survive container restart and redeploy:

  • uploaded assets
  • logs
  • database state

In practice, that means the server's files/ directory should be backed by a persistent volume or bind mount.

At minimum, preserve the container path that holds:

  • files/assets
  • files/logs
  • files/local.db

Environment Variables​

The most important container-time settings are:

  • SVR_SERVER_PORT
  • SVR_SERVER_FILES_DIR if you want to move persistent data outside the default path

You may also need deployment-specific settings related to logging or infrastructure routing.

Suggested Operator/Admin Checklist​

  1. Build or pull the correct image.
  2. Mount persistent storage for SVRunner data.
  3. Publish the container port to the expected host or ingress port.
  4. Set the required environment variables.
  5. Start the container.
  6. Confirm the app, docs, and GraphQL routes are reachable.
  7. Confirm that uploaded data survives a container restart.

Docker Deployment View Stub screenshot: container or orchestration view showing the mapped port, mounted persistent storage, and container health/running state. Save final image at packages/docs/screenshots/installation-docker-deployment-view.png.

Upgrade Guidance​

When upgrading a Docker deployment:

  • replace the image
  • preserve the mounted data volume
  • confirm the new container sees the existing files/ contents
  • validate the app, docs, GraphQL, and preview routes after startup

Treat the image as replaceable and the data volume as durable.
