API Examples

This page provides a small set of practical examples for the most common integration workflows.

Login​

mutation Login($input: LoginInput!) {
  login(input: $input) {
    user {
      id
      username
      role
    }
    sessionToken
  }
}

Example variables:

{
  "input": {
    "username": "operator1",
    "password": "example-password"
  }
}

After login, send the returned sessionToken in the Authorization header.

Authenticated Query​

query GetUser($id: Int!) {
  user(id: $id) {
    id
    username
    role
  }
}

Example curl:

curl "http://localhost:7376/graphql" \
  -H "Content-Type: application/json" \
  -H "Authorization: YOUR_SESSION_TOKEN" \
  --data '{
    "query": "query GetUser($id: Int!) { user(id: $id) { id username role } }",
    "variables": { "id": 1 }
  }'

List Query With Pagination​

query ListUsers(
  $where: UsersWhereInput
  $offset: Int
  $limit: Int
  $sort: SortInput
) {
  users(where: $where, offset: $offset, limit: $limit, sort: $sort) {
    items {
      id
      username
    }
    count
  }
}

Example variables:

{
  "offset": 0,
  "limit": 20,
  "where": {
    "firstName": {
      "contains": "Nat"
    }
  }
}

Asset Upload​

Use a multipart GraphQL request against createAsset or updateAsset.

Mutation shape:

mutation CreateAsset($input: CreateAssetInput!) {
  createAsset(input: $input) {
    id
    name
    fileName
    duration
  }
}

Example variables shape:

{
  "input": {
    "projectId": 1,
    "name": "Lobby Reel 01",
    "duration": 15,
    "file": null
  }
}

The binary file is supplied through multipart mapping rather than inline JSON.

Schedule Preview​

query GetSchedulePreview(
  $screenId: Int!
  $time: BigInt!
  $showUnpublished: Boolean
) {
  schedulePreview(
    screenId: $screenId
    time: $time
    showUnpublished: $showUnpublished
  ) {
    screen {
      id
      name
    }
    order {
      id
      type
    }
  }
}

Example variables:

{
  "screenId": 1,
  "time": 1718042400000,
  "showUnpublished": false
}

Enable Quick Play​

mutation EnableQuickPlay($input: EnableQuickPlayInput!) {
  enableQuickPlay(input: $input) {
    id
    quickPlayEnabled
    quickPlayId
  }
}

Example variables using an event:

{
  "input": {
    "projectId": 1,
    "eventId": 123
  }
}

Disable Quick Play​

mutation DisableQuickPlay($input: DisableQuickPlayInput!) {
  disableQuickPlay(input: $input) {
    id
    quickPlayEnabled
  }
}

Example variables:

{
  "input": {
    "projectId": 1
  }
}

Logs Query​

query ListLogs(
  $screenId: Int
  $playerId: Int
  $startTime: BigInt
  $endTime: BigInt
  $limit: Int
  $offset: Int
) {
  logs(
    screenId: $screenId
    playerId: $playerId
    startTime: $startTime
    endTime: $endTime
    limit: $limit
    offset: $offset
  ) {
    id
    assetId
    screenId
    playerId
    time
    duration
  }
}

License Activation​

mutation ActivateLicense($input: ActivateLicenseInput!) {
  activateLicense(input: $input) {
    id
    status
    expiresAt
    active
  }
}

API Examples Client Stub screenshot: API client captures next to the most important integration examples on this page. Save final image at packages/docs/screenshots/api-examples-client.png.
